Biomass Feeder

Name: Biomass Feeder
Brand: JAI KRISHNA ENGINEERING
Price: 1200000.0 INR
Availability: InStock

1200000.0 INR/Unit

Get a Price/Quote

Product Details:

Usage & Applications Continuous Feeding of Biomass Material in Boilers and Gasifiers
Speed Variable
Model No BF-1000
Frequency 50 Hz
Temperature Range Ambient
Efficiency (%) Up to 95%
Driven Type Gear Motor
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Biomass Feeder Price And Quantity

Minimum Order Quantity 1 Unit
Price 1200000.0 INR/Unit

Service Support Available
Maintenance Requirement Low
Lubrication Type Automatic/Manual
Feeding Control Method Variable Speed Controller
Discharge Height Adjustable 600-1200 mm
Inlet Size 400 x 300 mm
Safety Features Emergency Stop, Overload Protection
Feeding Accuracy 2%
Noise Level <70 dB
Operating Humidity 10-90% RH Non-Condensing
Feeding Mechanism Screw/Chain Conveyor

Biomass Feeder Product Specifications

Capacity 500-1000 kg/hr
Driven Type Gear Motor
Drive Type Electric Motor
Type Biomass Feeder
Temperature Range Ambient
Efficiency (%) Up to 95%
Machine Type Feeder Mechanism
Frequency 50 Hz
Surface Finish Powder Coated
Power Consumption 2.2 kW
Weight (kg) Approx. 350 kg
Speed Variable
Model No BF-1000
Usage & Applications Continuous Feeding of Biomass Material in Boilers and Gasifiers
Automatic Grade Automatic
Material Mild Steel
Dimension (L*W*H) 1500 x 900 x 1200 mm
Power 3 HP
Automation Grade Automatic
Installation Guideline On-Site Engineer Assistance Available
Computerized No
Accessories Control Panel, Hopper, Safety Guards
Color Green
Voltage 415 V
Control System PLC Based
Motor Power 3 HP
Production Capacity As per requirement
Features Robust Construction, Easy Operation, Corrosion Resistant, Low Maintenance

Service Support Available
Maintenance Requirement Low
Lubrication Type Automatic/Manual
Feeding Control Method Variable Speed Controller
Discharge Height Adjustable 600-1200 mm
Inlet Size 400 x 300 mm
Safety Features Emergency Stop, Overload Protection
Feeding Accuracy 2%
Noise Level <70 dB
Operating Humidity 10-90% RH Non-Condensing
Feeding Mechanism Screw/Chain Conveyor

Biomass Feeder Trade Information

Payment Terms Paypal, Cash Against Delivery (CAD), Cash Advance (CA), Cash in Advance (CID), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India

Product Description

A biomass feeder is an automated industrial system designed to convey materials like wood chips pellets agricultural waste or briquettes from storage into boilers furnaces or processing machinery These systems optimize combustion enhance safety and reduce manual labor by providing a consistent metered flow of fuel They commonly use screw feeders conveyors or hydraulic systems for consistent feeding

YouTube

Screw Feeder Moves materials using a rotating screw suitable for consistent volumetric feeding

Moving FloorHydraulic System Used in storage pits for largescale heavyduty material handling

ConveyorsElevators Bucket elevators or belts transport fuel to the feeding port

Storage and Metering Unit Manages stores and precisely dispenses the fuel

YouTube

Automation Eliminates daily manual feeding allowing for automatic scheduled refueling

Efficiency Ensures a consistent steady supply of fuel to the boiler improving combustion efficiency and temperature control

Versatility Handles a wide range of fuels including wood pellets wood chips sawdust briquettes and agricultural waste

Material Handling Often includes preprocessing such as shredding or crushing to ensure uniform fuel size for the boiler

YouTube

These systems are commonly applied in power plants industrial boiler setups and largescale heating applications with solutions often customized to the site

Precision Feeding for Industrial Biomass Applications

Designed to deliver reliable and accurate biomass material input, the BF-1000 Biomass Feeder is suitable for a wide range of industrial uses. Its variable speed controller and advanced PLC system guarantee up to 2% feeding accuracy, supporting both efficiency and operational flexibility. With a 500-1000 kg/hr capacity and adjustable discharge heights, it seamlessly integrates with boilers and gasifiers for diverse production needs.

Engineered for Safety, Durability, and Quiet Operation

Operator safety and machine longevity are central to the BF-1000's design. Emergency stop and overload protection features safeguard users and equipment, while the robust mild steel framework resists corrosion and wear. Automatic or manual lubrication extends operational life, and noise levels are kept below 70 dB for a comfortable work environment. Easy maintenance ensures minimal downtime.

Seamless Installation and Comprehensive Service Support

Installation of the BF-1000 is supported by on-site engineer assistance, ensuring proper setup and optimal performance. The feeder is delivered with essential accessories including a control panel, hopper, and safety guards. Ongoing service support is readily available, making this equipment a dependable addition to any biomass handling setup.

FAQ's of Biomass Feeder:

Q: How does the BF-1000 Biomass Feeder control and adjust the feeding rate?

A: The BF-1000 features a PLC-based variable speed controller, allowing precise adjustment of the feeding rate according to your process requirements. This ensures accurate and consistent delivery of biomass material into boilers or gasifiers.

Q: What safety measures are implemented in the BF-1000 Biomass Feeder?

A: Safety is a priority, with built-in emergency stop and overload protection mechanisms. Additionally, safety guards are fitted to protect operators during operation and maintenance.

Q: When is maintenance required, and how demanding is it for this feeder?

A: The BF-1000 is designed for low maintenance, thanks to robust construction and automatic or manual lubrication systems. Routine checks are typically sufficient, and minimal downtime is expected.

Q: Where can the BF-1000 Biomass Feeder be installed, and is support available?

A: This feeder can be installed at industrial locations such as boiler or gasifier facilities. On-site engineer assistance is provided for installation, and comprehensive service support is available throughout India.

Q: What is the process for continuous feeding of biomass material using this system?

A: Biomass material is loaded into the infeed hopper, passed through the inlet (400x300 mm), and conveyed via a screw or chain conveyor to the discharge point. The variable speed and PLC control maintain a steady flow tailored to your production needs.

Q: What are the benefits of using the BF-1000 Biomass Feeder in industrial applications?

A: Key benefits include high feeding accuracy (within 2%), low operating noise, robust and corrosion-resistant build, automatic operation, and easy adjustment for different material flows. This boosts operational efficiency and reliability in continuous biomass processing environments.

Q: Is the machine suitable for various climates and operating conditions?

A: Yes, it operates efficiently in ambient temperature ranges and for humidity levels of 10-90% RH (non-condensing), making it suitable for a wide range of industrial environments.
